Do You Know The Knowledge of Flat Cutting Machine



concept



For tasks that require high precision and processing of medium-weight materials, flat cutting.The machine is the most ideal. At the same time, the flatbed cutter is also suitable for presenting your complex and exquisite designs on sticky notes, mask films, foam boards, cardboard, oily boards, sandblasted rubber and other media.


The Automatic Flatbed Cutter has the ability to load a carving knife and a drawing pen at the same time. Therefore, the sample clothing/shoe sample designer can mark on the medium and then continue cutting, the user does not need to manually replace the corresponding drawing pen and cutter.


In addition, some flatbed cutting machines also have a positioning mark detection sensor as a standard equipment, which can easily recalibrate the position on the die-cutting medium that has already printed an image.



Scope of application



Compared with the friction-driven drum type carving machine, the Flatbed Cutting machine can use more materials, so the application range is also broader, such as: shop door, fluorescent signs, body advertising, sunshades, and the production of personalized T-shirts Thermal transfer pattern, packaging design, clothing proofing, mask film, sandblasted rubber template, etc.



Absorption material method



The flatbed cutter has three different media fixing systems:


Flatbed Cutting

Flatbed Cutting

1. Magnetic adsorption system



If processing thin and hard media, this is an economical choice, because this kind of media can be fixed along the edges.



2. Electrostatic adsorption system



This is a versatile mid-range option. For example, when processing soft media such as paper, the entire surface can be fixed by electrostatic adsorption.



3. Vacuum adsorption system



If you want to deal with thick and heavy media such as corrugated paper, card stock or PVC up to 40 mil (1 mm) thick, this will be your best choice.


Steps


Before use, fix the material flat on the cutting mat of the flatbed cutting machine, and adjust the parameters of the flatbed cutting plotter according to the materials and software used to achieve the best cutting effect.


When using, the user first creates the required graphics by installing the graphic editing and processing software matched with the Flat Cutting Plotter in the computer. After completing the design of the required engraving content, the user can issue instructions to the flatbed cutting machine through the computer. The cutter of the flat cutting machine is controlled and driven by the computer, and the characters and images that have been designed on the computer are carved on the objects to be carved. Flatbed cutters can also be used to cut and make paper cartons or engrave materials in thin metal.
